Male Connector Fuel Tank Cover EV Charger Cable For Automobile

Male Connector Fuel Tank Cover EV Charger Cable For Automobile

IEC 62196-2 EV Charger Cable

HDR Interface EV Charger Cable

IEC 62196-2 Automobile Charging Cable

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Model NO.:
LK-A01
Classification:
Male Connector
Interface Type:
HDR
Shape:
Circular
VSWR:
Straight
Medium Pressure:
1500V
Brand:
Linke
Plug Type:
IEC 62196-2 (Type 2), SAE J1772 Type 1
Conductor:
Bare Copper
Structure:
3034/0.20
Jacket:
Silicone
Use:
Charging
After-Sales Service:
1 Year
Warranty:
1year
Transport Package:
Roll
Specification:
5M
Trademark:
LINKE
Origin:
China
HS Code:
94054090
Supply Ability:
100000000
Package Size:
60.00cm * 55.00cm * 50.00cm
Package Gross Weight:
118.000kg
Type:
Fast EV Charging Station
Coupling Mechanism:
Threaded Connection
Application:
Power, Automobile
Samples:
US$ 1000/PCS 1 PCS(Min.Order) |
Customization:
Available | Customized Request
Shipping Cost:
About Shipping Cost And Estimated Delivery Time.
 :
Initial Payment Full Payment
Currency:
US$
Return&refunds:
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.
Highlight:

IEC 62196-2 EV Charger Cable

,

HDR Interface EV Charger Cable

,

IEC 62196-2 Automobile Charging Cable

Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
按规格报价
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
Product Description

Shipping Cost And Estimated Delivery Time Fuel Tank Cover Cable For Toyota Hilux Revo

Automobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover Cable

SPECIFICATION CABLE NAME EV Cable
CABLE SPEC 2C×80mm2+1C×25mm2+2C×4mm2+(3C×0.75mm2)(P2)+(7C×0.75mm2)
RoHS  Compliant
Item : 2C×80mm2 : 1C×25mm2 : 1C×4mm2 D:(3C×0.75mm2)(P2) E:(7C×0.75mm2)
CONDUCTOR Material Bared copper stranded
Size 2580/0.20 ±0.008mm 798/0.20 ±0.008mm 224/0.15±0.008mm
+10/1#Tinsel+1000D Kevlar
40/0.15±0.008mm+
10/0.19mmTinsel+200DKevlar
40/0.15±0.008mm+
10/0.19mmTinsel+200D
Kevlar
O.D.(Ref.) 12.40±0.25mm 7.00±0.20mm   2.70±0.15mm 1.40±0.10mm 1.40±0.10mm
INSULATION Material Thermoplastic(EF2585,85±3A)
Min. average thickness 1.60mm 1.20mm 1.00mm 0.50mm 0.50mm
Min.thickness at any point 1.34mm 0.98mm 0.80mm 0.35mm 0.35mm
O.D. 15.60±0.40mm 9.60±0.30mm 4.70±0.20mm 2.50±0.10mm 2.50±0.10mm
CABLING-1 Filler / Cotton Cotton
Material / AL-mylar(facing out) Non-woven
BRAID Material / Tinned  copper /
Size / 0.12mm,≥60% /
In-JACKET Material / TPE TPE
Min. average thickness / 0.60mm 0.60mm
Min.thickness at any point / 0.42mm 0.42mm
O.D. / 7.20±0.25mm 9.70±0.25mm
CABLING Filler Strengthed  PP  rope
Material Non-woven(≥25% overlapping)
Assembly 2C×80mm2+1C×25mm2+2C×4mm2+(3C×0.75mm2)(P2)+(7C×0.75mm2)
JACKET Material TPU
Min. average thickness 2.80mm
Min.thickness at any point  2.28mm
O.D. 38.00+0.6/-1.00mm

ELECTRICAL CHARACTERISTICS PHYSICAL PROPERTIES
Rated voltage:DC 1000V Tensile strength:≥20MPa High temperature pressure test:≤50%
Rated temperature:Jacket  -40~90ºC Elongation:≥300% Heat shock test:No  crack
                                 Insulation  -40~125ºC Aged condition:110±1ºC×168h Compatibility test:GB/T 33594
Max. conductor resistance(20ºC): Percent of original tensile strength:≤±30% Crush resistance test:GB/T 33594
A:0.242Ω/km  B:0.78Ω/km  C:4.95Ω/km   D&E:26Ω/km Percent of original elongation:≤±30% Curved around the test:GB/T 33594
Insulation  Voltage withstand(Core A&B,10m): Flame  test:GB/T 18380.12-2008 Min.  Bend  radius:6*OD
AC 2.5kV/5min,leakage current ≤5mA Artificial weathering test:GB/T 33594 Abrasion resistance:≥2000times
Completed cable  Voltage withstand(Core A  to A&B,10m): Low-temperature impact test :-40ºC×16H,No  crack Resistance against chemicals:GB/T 33594
AC 3.5kV/15min,leakage current ≤5mA Chemical stress acidN-Oxal-acid alkaline solution, N-sodium hydroxide solution:GB/T 33594
Min. Insulation resistance(20ºC, Core A  to  A&B):500MΩ.km Vehicle rolling:Requirements and test methods should be consistent with GB/T 20234.1-2015 7.21
Structure
NO. conductor                 mm2 insulution 20ºC conductor resistance             (Ω/KM)
conductor                 mm2 Structure(N/mm)  Conductor DIA(mm) Conductor  Thickness (mm) MATERIAL insulution OD          (mm)
EV-YJ 1.5 48/0.20 1.60  copper  0.6 silicone 2.90±0.15 ≤12.7
EV-YJ 2.5 80/0.20 2.06  copper  0.7 silicone 3.50±0.15 ≤7.60
EV-YJ 128/0.20 2.62  copper  0.8 silicone 4.30±0.15 ≤4.71
EV-YJ 196/0.20 3.50  copper  0.8 silicone 5.10±0.20 ≤3.14
EV-YJ 10  322/0.20 4.50  copper  1.00  silicone 6.70±0.20 ≤1.82
EV-YJ 16  513/0.20 5.70  copper  1.10  silicone 8.00±0.30 ≤1.16
EV-YJ 25  798/0.20 7.10  copper  1.3 silicone 9.80±0.30 ≤0.743
EV-YJ 35  1121/0.20 8.50  copper  1.3 silicone 11.40±0.30 ≤0.527
EV-YJ 50  1596/0.20 10.10  copper  1.50  silicone 13.50±0.30 ≤0.368
EV-YJ 70  2242/0.20 12.10  copper  1.50  silicone 15.50±0.40 ≤0.259
EV-YJ 95  3034/0.20 14.10  copper  1.50  silicone 17.50±0.50 ≤0.196

Automobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover Cable
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C


2,Low viscosity appearance
Automobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover Cable
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
Automobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover Cable
Automobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover CableAutomobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover CableAutomobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover CableAutomobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover CableAutomobile Parts Wire for Toyota Hilux Revo Fuel Tank Cover Cable
