5M 32A EV Car Charging Station Electric Vehicle Cable Conductor Bare Copper

5M 32A EV Car Charging Station Electric Vehicle Cable Conductor Bare Copper

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Model NO.:
LK-EV22
Jacket:
Silicone
Use:
Charging
After-sales Service:
1 Year
Type:
Slow EV Charging Station
Warranty:
1year
Transport Package:
Roll
Specification:
5M
Trademark:
LINKE
Origin:
China
HS Code:
94054090
Supply Ability:
100000000
Package Size:
60.00cm * 60.00cm * 60.00cm
Package Gross Weight:
30.000kg
Plug Type:
IEC 62196-2 (Type 2), SAE J1772 Type 1
Conductor:
Bare Copper
Structure:
3034/0.20
Samples:
US$ 1000/PCS 1 PCS(Min.Order) |
Customization:
Available | Customized Request
Shipping Cost:
About Shipping Cost And Estimated Delivery Time.
 :
Initial Payment Full Payment
Currency:
US$
Return&refunds:
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.
Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
Product Description

5M 32A EV Car Charging Station Electric Vehicle Cable Conductor Bare Copper

High Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle Cable
High Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle Cable



SPECIFICATION CABLE NAME EV Cable
CABLE SPEC 2C×80mm2+1C×25mm2+2C×4mm2+(3C×0.75mm2)(P2)+(7C×0.75mm2)
RoHS  Compliant
Item : 2C×80mm2 : 1C×25mm2 : 1C×4mm2 D:(3C×0.75mm2)(P2) E:(7C×0.75mm2)
CONDUCTOR Material Bared copper stranded
Size 2580/0.20 ±0.008mm 798/0.20 ±0.008mm 224/0.15±0.008mm
+10/1#Tinsel+1000D Kevlar
40/0.15±0.008mm+
10/0.19mmTinsel+200DKevlar
40/0.15±0.008mm+
10/0.19mmTinsel+200D
Kevlar
O.D.(Ref.) 12.40±0.25mm 7.00±0.20mm   2.70±0.15mm 1.40±0.10mm 1.40±0.10mm
INSULATION Material Thermoplastic(EF2585,85±3A)
Min. average thickness 1.60mm 1.20mm 1.00mm 0.50mm 0.50mm
Min.thickness at any point 1.34mm 0.98mm 0.80mm 0.35mm 0.35mm
O.D. 15.60±0.40mm 9.60±0.30mm 4.70±0.20mm 2.50±0.10mm 2.50±0.10mm
CABLING-1 Filler / Cotton Cotton
Material / AL-mylar(facing out) Non-woven
BRAID Material / Tinned  copper /
Size / 0.12mm,≥60% /
In-JACKET Material / TPE TPE
Min. average thickness / 0.60mm 0.60mm
Min.thickness at any point / 0.42mm 0.42mm
O.D. / 7.20±0.25mm 9.70±0.25mm
CABLING Filler Strengthed  PP  rope
Material Non-woven(≥25% overlapping)
Assembly 2C×80mm2+1C×25mm2+2C×4mm2+(3C×0.75mm2)(P2)+(7C×0.75mm2)
JACKET Material TPU
Min. average thickness 2.80mm
Min.thickness at any point  2.28mm
O.D. 38.00+0.6/-1.00mm

ELECTRICAL CHARACTERISTICS PHYSICAL PROPERTIES
Rated voltage:DC 1000V Tensile strength:≥20MPa High temperature pressure test:≤50%
Rated temperature:Jacket  -40~90ºC Elongation:≥300% Heat shock test:No  crack
                                 Insulation  -40~125ºC Aged condition:110±1ºC×168h Compatibility test:GB/T 33594
Max. conductor resistance(20ºC): Percent of original tensile strength:≤±30% Crush resistance test:GB/T 33594
A:0.242Ω/km  B:0.78Ω/km  C:4.95Ω/km   D&E:26Ω/km Percent of original elongation:≤±30% Curved around the test:GB/T 33594
Insulation  Voltage withstand(Core A&B,10m): Flame  test:GB/T 18380.12-2008 Min.  Bend  radius:6*OD
AC 2.5kV/5min,leakage current ≤5mA Artificial weathering test:GB/T 33594 Abrasion resistance:≥2000times
Completed cable  Voltage withstand(Core A  to A&B,10m): Low-temperature impact test :-40ºC×16H,No  crack Resistance against chemicals:GB/T 33594
AC 3.5kV/15min,leakage current ≤5mA Chemical stress acidN-Oxal-acid alkaline solution, N-sodium hydroxide solution:GB/T 33594
Min. Insulation resistance(20ºC, Core A  to  A&B):500MΩ.km Vehicle rolling:Requirements and test methods should be consistent with GB/T 20234.1-2015 7.21
Structure
NO. conductor                 mm2 insulution 20ºC conductor resistance             (Ω/KM)
conductor                 mm2 Structure(N/mm)  Conductor DIA(mm) Conductor  Thickness (mm) MATERIAL insulution OD          (mm)
EV-YJ 1.5 48/0.20 1.60  copper  0.6 silicone 2.90±0.15 ≤12.7
EV-YJ 2.5 80/0.20 2.06  copper  0.7 silicone 3.50±0.15 ≤7.60
EV-YJ 128/0.20 2.62  copper  0.8 silicone 4.30±0.15 ≤4.71
EV-YJ 196/0.20 3.50  copper  0.8 silicone 5.10±0.20 ≤3.14
EV-YJ 10  322/0.20 4.50  copper  1.00  silicone 6.70±0.20 ≤1.82
EV-YJ 16  513/0.20 5.70  copper  1.10  silicone 8.00±0.30 ≤1.16
EV-YJ 25  798/0.20 7.10  copper  1.3 silicone 9.80±0.30 ≤0.743
EV-YJ 35  1121/0.20 8.50  copper  1.3 silicone 11.40±0.30 ≤0.527
EV-YJ 50  1596/0.20 10.10  copper  1.50  silicone 13.50±0.30 ≤0.368
EV-YJ 70  2242/0.20 12.10  copper  1.50  silicone 15.50±0.40 ≤0.259
EV-YJ 95  3034/0.20 14.10  copper  1.50  silicone 17.50±0.50 ≤0.196

High Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle Cable
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C


2,Low viscosity appearance
High Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle Cable
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
High Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle CableHigh Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle CableHigh Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle CableHigh Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle CableHigh Quality 3*6+2*0.5 32A EV Car Charging Station Electric Vehicle Cable
Company Profile:

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China. In the past over 10 years,

Linke Cable has been focusing on R&D, production and marketing of wire and cable. Linke provide various cables&custom

cable solutions for all over the world. We are specialized in EV charging cable, medical cable, silicone cable, spring cable,

braided cable, towlobe cable, UL wire, automotive cable, etc.

At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-engineer approach

to develop better cables for customers and  improve the quality of one's life.


Our certification:

We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269(Single conductor,thermoplastic insulation)
UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,UL2587,

UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664

ISO9001 and ISO13485,TS16949

CNR- Appliance Wiring Material,

Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.

Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.
Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2

FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.

Welcome to visit us. We'll pick you up in Shenzhen.


2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.



3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.



4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.



5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company
