Waterproof Cable is designed for signal transmission, control, and measurement systems in electrical apparatus and power distribution equipment across metallurgy, power, and petrochemical industries. Rated voltage up to 450/750V.
Water-Resistant Cable Selection Guide
- 750V, blue, submersible-pump cable
- 750V, blue, submersible pump cable
- H07 RN8-F waterproof rubber-sheathed cable, harmonized type
Waterproof Cable Specifications
Waterproof Flat Submersible Pump Cable 1.5mm
4-Core Flat Cables for Submersible Pumps (1100 Volts)
| Conductor |
Rubber Insulation |
Rubber Sheath |
Conductor Resistance at 20°C (max) ohms/km |
Current Rating at 40°C Amps |
| 1.5 mm² |
0.8 mm |
1.3 mm |
12.1 |
14 |
| 2.5 mm² |
0.9 mm |
1.3 mm |
7.41 |
18 |
| 4 mm² |
1.0 mm |
1.45 mm |
4.95 |
26 |
| 6 mm² |
1.0 mm |
1.5 mm |
3.3 |
31 |
| 10 mm² |
1.0 mm |
1.8 mm |
1.91 |
42 |
| 16 mm² |
1.0 mm |
1.95 mm |
1.21 |
57 |
| 25 mm² |
1.2 mm |
2.0 mm |
0.78 |
72 |
| 35 mm² |
1.2 mm |
2.0 mm |
0.554 |
90 |
| 50 mm² |
1.4 mm |
2.2 mm |
0.386 |
115 |
| 70 mm² |
1.4 mm |
2.2 mm |
0.272 |
143 |
| 95 mm² |
1.6 mm |
2.4 mm |
0.206 |
165 |
Key Features
- Excellent resistance to moisture, abrasion, grease, and oil
- Superior mechanical and electrical properties
- Wide temperature range: -40°C to 90°C
Advanced Waterproof Cable Specifications
- Extreme temperature range: -40°C to 105°C - withstands automotive environment extremes
- Available in various gauges: 0GA, 2GA, 4GA, 6GA, 8GA, 10GA, 12GA, 14GA, 15GA, 16GA, 18GA, 20GA and ultra classic strands
- High strand counts for enhanced flexibility
- Conductor Type: Stranded 99.99% OFC (oxygen free copper), tin plated copper, copper coated aluminum
- Material: Environmentally friendly, high-quality glossy material
- Plating options: Tinned, Silver or Nickel plated copper
- Custom colors available
- Packing options: carton packing, pallet packing, wooden/plastic reels
We can manufacture Waterproof Cable according to customers' specific requirements.
| Brand |
LINKE |
Cross Section (mm²) |
0.01-500mm² |
| Wire Gauge (AWG) |
[e.g., 24AWG, 28AWG] |
Conductor |
Tinned Copper /bare copper, based on client's requirements |
| Insulation material |
PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other |
Jacket Material |
[PVC/PU/Rubber/Braid/etc.] |
| Certifications |
RoHS/REACH/UL/CE/IP68/etc |
Custom Length |
[e.g., 1m, 3ft, 5m ±5% tolerance] |
| Cable Type |
[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] |
Shielding |
[Shielded/Unshielded/Braid Shield] |
| Impedance |
[e.g., 75Ω (for coaxial cables)] |
Printing/Logo |
[Text/Label/Logo, max. 20 characters] |
| Bend Radius |
[e.g., ≥5× cable diameter] |
Current Rating |
[e.g., 5A] |
| Voltage Rating |
[e.g., 30V AC/DC] |
Connector Material |
[Gold-plated/Nickel-plated/Brass/etc.] |
| Connectors |
[e.g., USB Type-C, 3.5mm Jack, RJ45] |
Jacket |
XLPE or PE or PVC RUBBER |
| Delivery Time |
7-14 days after confirming the order |
Colors |
[Black/White/Red/Custom Pantone/etc.] |
| temperature |
Minus-70℃to 350℃(-70℃ ~ 350℃) |
Package |
Roll/box/plate/Custom |
| Supporting Services |
multicolumn {3}{l}{custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated) |
|
|
Independent Laboratory • Complete Testing Equipment • Full Quality Control
We test every product by strict standards to ensure superior quality and reliable performance.
|
No.
|
Test Item
|
Test Condition
|
Test Requirement
|
Test Data
|
Result
|
|
1
|
Structure Inspection
|
1. Comply with wire size table2. Minimum thickness ≥ 80% of average thickness
|
Comply with wire size table
|
Refer to test record
|
Pass
|
|
2
|
Thermal Shock
|
Wind the sample on an iron rod of specified size, place in an aging oven at specified temperature for 1 hour, cool the sample to room temperature for at least 30 minutes, then observe the sample
|
No cracks on the sample surface
|
No cracks
|
Pass
|
|
3
|
Heat Deformation
|
1. Measure sample thickness (mark measurement position)2. Place sample and test fixture in aging oven for preheating at specified temperature for 1 hour3. Place sample under pressure column of test fixture for 1 hour4. Re-measure sample thickness at the same position
|
1. Sample shall not be cracked by pressure column or expose conductor2. Thickness reduction ≤ 50%
|
Refer to test record
|
Pass
|
|
4
|
FT2
|
Apply a standard flame at a height of 125mm once
|
1. Flame shall not propagate along its length2. Flame shall not spread to nearby flammable materials
|
Refer to test record
|
Pass
|
|
5
|
Aging
|
1. Take five sections of 200mm-long sheath2. Place specimens in aging oven at 158℃ for 168 hours3. After taking out specimens, place at room temperature 23±5℃ for 16 hours, then test elongation at break and tensile strength
|
1. Elongation before aging ≥ 300%, elongation after aging ≥ 80% of that before aging2. Tensile strength before aging > 1.41kg/mm², tensile strength after aging ≥ 80% of that before aging
|
Refer to test record
|
Pass
|
|
6
|
Cold Bend
|
Store sample in low-temperature box at specified temperature for 4 hours, wind sample on iron rod of specified size with specified turns, complete winding within 30 seconds after sample is taken out of low-temperature box
|
No cracks on the sample surface
|
No cracks
|
Pass
|
|
7
|
Conductor Resistance
|
Measure resistance of one-meter core conductor with DC resistance meter
|
At 20℃, resistance of 8AWG ≤ 2.23Ω/km
|
Refer to test record
|
Pass
|
Linke cable technology (DongGuan) Co. Ltd. concentrate on R&D and
provide professional solutions to the Cable&Wire,especially for the
different industry customers.It contains :
Humanoid robot cable,
AI power cable/data cable,
Semiconductor cable/industrial automatic cable,
Sensor cable,
New energy cable,
Medical beauty wire,
UL wire cable,
Linke Cable has diversified product development capabilities and technical capabilities to support diversified
customer needs. We have obtained the following product authorization:UL 758,CCC,RoHs,REACH,CE; We
have obtained the following quality management system:ISO 9001-2015(All products); ISO 13485
(Medical apparatus and instruments),IATF 16949(Auto industry)
Company Profile
Linke Cable Technology Co., Ltd is a leading wire and cable manufacturer and supplier in China. For over 10 years, Linke Cable has specialized in R&D, production, and marketing of high-quality cables and custom cable solutions for global markets.
Specialized Cable Solutions
- EV charging cable
- Medical cable
- Silicone cable
- Spring cable
- Braided cable
- Towlobe cable
- UL wire
- Automotive cable
At Linke Cable, we employ an engineer-to-engineer approach to develop superior cables for our customers and enhance quality of life through innovative solutions.
Certifications
Single-conductor, Thermoplastic Insulation
1007, 1015, 1185, 1330, 1331, 1332, 1333, 1569, 1577, 1591, 1592, 1672, 1723, 1901, 10012, 10064, 10070, 10269, 10369, 10483
Multiple-conductor, Thermoplastic Insulation
2095, 2103, 2104, 2129, 2463, 2464, 2468, 2517, 2576, 2586, 2587, 2661, 2725, 2835, 2919, 20233, 20276, 20279, 20280, 20549, 20886, 20963, 21198, 21664
Single-conductor, Thermoset Insulation
3075, 3123, 3132, 3135, 3173, 3212, 3266, 3271, 3320, 3321, 3331, 3385, 3386, 3398, 3512, 3529, 3530, 3577, 3644, 3674, 3689, 3702, 3817, 3886, 30005
Frequently Asked Questions
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We manage your order from start to finish. Welcome to visit us - we provide pickup service in Shenzhen.
2. How can I get a sample to test your quality?
Samples are free for qualified customers. New clients are expected to pay for courier costs.
3. What's your Minimum Order Quantity?
Normally 100m. However, cables can be heavy. We recommend ordering suitable quantities to optimize freight costs. Sea transportation is often the most cost-effective option.
4. Can I get a discount?
Discounts are available based on order quantity. We may also offer freight support. Please contact us for details.
5. Does your company accept OEM production?
Yes, we can print your company name and even customize quality cards to promote your brand.
