300V Rated ROV Floating Cable with Temperature Range -50 to +80°C and Mobile Bending Installation Radius 5-7.5*D

Waterproof Rov Floating Cable

Submarine Rov Floating Cable

TPE Sheath Rov Cable

Place of Origin:

China

Brand Name:

linkecable

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Name:

Rov Floating Cable

Jacket:

TPE

Conductor Material:

Copper/Tinned Copper

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Colour:

Customize

Type:

Insulated

Package:

By Roll

Lead Time:

7-15days

Highlight:

Waterproof Rov Floating Cable

Submarine Rov Floating Cable

TPE Sheath Rov Cable

Payment & Shipping Terms

Minimum Order Quantity

1000m

Price

Negotiable

Packaging Details

Security

Delivery Time

7-15 days

Supply Ability

50000m/day

Tinned Wire Core Cable for Larger Buoyancy on Water Floating and Efficiency cable solutions thermoset insulation

Get Best Price

Floating Cable 1200A PP Insulated Copper Conductor for ROV

Get Best Price

Linke TPU Floating Cable 300V Multi-Core Tinned Copper Wire

Get Best Price

TPE Sheath Floating Cable for Underwater Robots and Pools

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

TPE Underwater Zero Buoyancy Cable Wire ROV Floating Cable Waterproof For Submarine

Floating cable relies on foam core extrusion capabilities to achieve precise cable buoyancy requirements. It is flexible, movable, UV-stable, with good bendability and abrasion resistance. Available with various jacket options for resistance to chemicals including acids, salt water, oil, and gasoline. Ideal for powering and controlling robotic cleaning systems in swimming pools, aquarium facilities, marine applications, and submersible environmental pumping systems.

Key Features

Zero buoyancy design prevents sinking under its own weight
Excellent resistance to moisture, abrasion, grease, and oil
Superior mechanical and electrical characteristics
Oil resistant, corrosion resistant, acid and alkali resistant
Seawater resistant, hydrolysis resistant, high tensile strength
Anti-corner biting design with high safety

Applications

Designed for underwater power, signal transmission, and control communication. Primarily used for:

Underwater robots (ROV)
Underwater detection systems
Underwater construction equipment
Underwater imaging systems
Underwater monitoring devices
Submersible pumps and environmental systems

Product Structure

Conductor: Multi-strand fine tinned copper wire
Insulation: Foamed thermoplastic elastomer/TPE/TPV materials
Core wire structure: Anti-twist layered structure with grouped gap filling
Tensile reinforcement: Kevlar center or gap filling with optional Kevlar tensile braided mesh layer
Inner sheath: Low viscosity strong extrusion inner sheath (customizable)
Outer sheath: Foamed polyurethane material

Technical Specifications

Rated voltage	300/500V
Temperature range	-50°C to +80°C
Water pressure resistance (longitudinal)	4.5MPa to 10.0MPa
Water pressure resistance (transverse)	10.0MPa to 70MPa
Mobile bending installation radius	5-7.5× cable outer diameter
Tensile strength	260kg-2T (customizable)
Waterproof depth	1000m

Buoyancy Material Comparison

Material Type	Characteristics	Applications
Polyurethane foam	Density: 0.05-0.25g/cm³, max depth: 200m	Pipeline floating, mooring buoys, short-term emergency floating
Copolymer foam	Density: 0.04-0.4g/cm³, max depth: 600m	ROV floating materials, umbilical floating, submersible cabin
Composite foam	Density: 0.275-0.65g/cm³, max depth: full ocean depth	Deepwater ROV, riser devices, deepwater pipeline floating

About Linke Cable Technology Co., Ltd

Linke Cable Technology Co., Ltd is a leading cable manufacturer in China with over 10 years of experience in R&D, production, and marketing of specialized cables. We provide custom cable solutions worldwide, specializing in EV charging cables, medical cables, silicone cables, spring cables, and various industrial cables.

Our engineer-to-engineer approach ensures we develop better cables tailored to customer needs while improving quality and performance.

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We control the entire production process from beginning to end. Welcome to visit our facility in Shenzhen.

How can I get a sample to test your quality?

Samples are free for evaluation. New clients are responsible for courier costs.

What's your Minimum Order Quantity?

Standard MOQ is 100m. Due to weight considerations, we recommend sea transportation for optimal freight costs.

Can I get a discount?

Discounts are available based on order quantity. We may also offer freight subsidies for larger orders.

Does your company accept OEM production?

Yes, we offer complete OEM services including custom branding and quality cards to promote your company.
