Silicone Rubber Tinned Copper Wire 600V/200c Cable for Customized Lighting Solutions

Silicone Rubber Tinned Copper Wire 600V/200c Cable for Customized Lighting Solutions

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Model NO.:
LK-C90
AMP:
1200A
Color:
Customized
Customized:
Customized
Material:
Silicone
Conductor:
Tinned Copper
Insulation:
Silicone
Jacket:
Silicone
Voltage:
300V
Use:
Internal Wiring Of Vehicle
Transport Package:
Roll
Specification:
80*80*69CM
Trademark:
LINKE
Origin:
China
HS Code:
94054090
Supply Ability:
100000000
Package Size:
80.00cm * 80.00cm * 69.00cm
Package Gross Weight:
250.000kg
After-sales Service:
1year
Warranty:
1year
Certification:
RoHS, TUV, CE, ISO
Samples:
US$ 1000/PCS 1 PCS(Min.Order) |
Customization:
Available | Customized Request
Shipping Cost:
About Shipping Cost And Estimated Delivery Time.
 :
Initial Payment Full Payment
Currency:
US$
Return&refunds:
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.
Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
每天几W米
Product Description

Silicone Rubber Tinned Copper Wire 600V/200c Cable for Customized Lighting Solutions

Silicone Rubber Tinned Copper Wire 600V/200c For Lighting

Product Description


Silicone Rubber Tinned Copper Wire 600V/200c Cable for Lighting

Product Range:

Automotive wireharness,Appliance wireharness,Robot wireharness,Medical wireharness and etc.
Test: Professional breakover and pulling force test before shipment
Cable materials:  Wire harness can be UL/CSA,CE,  etc and pure copper
Cable color,length: According to the customers' requirements
Insulation: Rubber,Silicon,PE,...etc
Connector and Terminal Type Original OEM or Replacement
Application Automotive,Appliance equipment,Medical equipment and etc
MOQ 1000PCS
Samples Samples confirmed first before mass production
Certificates ISO9001-2015, IATF16949-2016, CE, RoHS, SGS, TUV
Lead time 10-20days
Service OEM and ODM, we accept customization according to your requirement
Nominal Voltage 300V,300/500V,600V,30V,450/750V etc…
Temperature Range  -30ºC~+80ºC,-30ºC~+90ºC,-30ºC~+105ºC,-30ºC~+70ºC/90ºC,105/180ºC, 200ºC etc….
Lead time Small orders under 500pcs is 5-7days,exceed 1000pcs 7-15days
Payment T/T, L/C,PayPal,Western Union

Structure
NO. conductor                 mm2 insulution 20ºC conductor resistance             (Ω/KM)
conductor                 mm2 Structure(N/mm)  Conductor DIA(mm) Conductor  Thickness (mm) MATERIAL insulution OD          (mm)
EV-YJ 1.5 48/0.20 1.60  copper  0.6 silicone 2.90±0.15 ≤12.7
EV-YJ 2.5 80/0.20 2.06  copper  0.7 silicone 3.50±0.15 ≤7.60
EV-YJ 128/0.20 2.62  copper  0.8 silicone 4.30±0.15 ≤4.71
EV-YJ 196/0.20 3.50  copper  0.8 silicone 5.10±0.20 ≤3.14
EV-YJ 10  322/0.20 4.50  copper  1.00  silicone 6.70±0.20 ≤1.82
EV-YJ 16  513/0.20 5.70  copper  1.10  silicone 8.00±0.30 ≤1.16
EV-YJ 25  798/0.20 7.10  copper  1.3 silicone 9.80±0.30 ≤0.743
EV-YJ 35  1121/0.20 8.50  copper  1.3 silicone 11.40±0.30 ≤0.527
EV-YJ 50  1596/0.20 10.10  copper  1.50  silicone 13.50±0.30 ≤0.368
EV-YJ 70  2242/0.20 12.10  copper  1.50  silicone 15.50±0.40 ≤0.259
EV-YJ 95  3034/0.20 14.10  copper  1.50  silicone 17.50±0.50 ≤0.196


Company Profile

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.

In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of

wire and cable. Linke provide various cables&custom cable solutions for all over the world.

We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,

towlobe cable, UL wire, automotive cable, etc.

At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-

engineer approach to develop better cables for customers and  improve the quality of one's life.
Silicone Rubber Tinned Copper Wire 600V/200c Cable for LightingSilicone Rubber Tinned Copper Wire 600V/200c Cable for Lighting


Certifications

We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269

(Single conductor,thermoplastic insulation)

UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,UL2587,

UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664

ISO9001 and ISO13485,TS16949

CNR- Appliance Wiring Material,

Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.

Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.

Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.

Single-conductor, thermoplastic insulation
1007 1330 1333 1591 1723 10064 10369
1015 1331 1569 1592 1901 10070 10483
1185 1332 1577 1672 10012 10269
Multiple-conductor, thermoplastic insulation
2095 2129 2468 2586 2725 20233 20280 20963
2103 2463 2517 2587 2835 20276 20549 21198
2104 2464 2576 2661 2919 20279 20886 21664
Single-conductor, thermoset insulation
3075 3173 3320 3386 3530 3689 30005
3123 3212 3321 3398 3577 3702
3132 3266 3331 3512 3644 3817
3135 3271 3385 3529 3674 3886


Silicone Rubber Tinned Copper Wire 600V/200c Cable for LightingSilicone Rubber Tinned Copper Wire 600V/200c Cable for Lighting



FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.

Welcome to visit us. We'll pick you up in Shenzhen.


2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.



3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.



4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.


5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
