Performance Characteristics
| ELECTRICAL CHARACTERISTICS | PHYSICAL PROPERTIES |
|---|
| Rated voltage: DC 1000V | Tensile strength: ≥20MPa |
Rated temperature: Jacket -40~90ºC
Insulation -40~125ºC | Elongation: ≥300% |
Max. conductor resistance(20ºC):
A:0.242Ω/km B:0.78Ω/km
C:4.95Ω/km D&E:26Ω/km | Aged condition: 110±1ºC*168h |
Insulation Voltage withstand(Core A &B,10m):
AC 2.5kV/5min,leakage current ≤5mA | Percent of original tensile strength: ≤±30% |
Completed cable Voltage withstand(Core A to A &B,10m):
AC 3.5kV/15min,leakage current ≤5mA | Percent of original elongation: ≤±30% |
| Min. Insulation resistance(20ºC, Core A to A &B):500MΩ.km | Flame test: GB/T 18380.12-2008 |
| Artificial weathering test: GB/T 33594 |
| Low-temperature impact test: -40ºC*16H,No crack |
| Chemical stress acid: N-Oxal-acid alkaline solution, N-sodium hydroxide solution:GB/T 33594 |
| Vehicle rolling: Requirements and test methods should be consistent with GB/T 20234.1-2015 7.21 |
Additional Test Standards
High temperature pressure test: ≤50%
Heat shock test: No crack
Compatibility test: GB/T 33594
Crush resistance test: GB/T 33594
Curved around the test: GB/T 33594
Min. Bend radius: 6*OD
Abrasion resistance: ≥2000times
Resistance against chemicals: GB/T 33594
Product Features
Conductor: Flexible Bare annealed copper wire
Insulation: Silicone
Color Options: Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated
SQ MM sizes (European style): 4 sq mm to 240 sq mm
AWG sizes (North American style): 0AWG-10AWG
Wide temperature range: -60°C to 200°C
Low viscosity appearance
Quality Certifications
• UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
• UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
• ISO9001 and ISO13485, TS16949
• CNR- Appliance Wiring Material
• Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
• Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
• Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Frequently Asked Questions
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.
4. Can I get a discount?
It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.
5. Does your company accept OEM production?
Yes, we can print your company name, and we even custom the quality card to promote your company.
