UL TUV Certified Fire Retardant Cable with PVC Sheath and XLPE Insulation
Thermocouple compensation cables, also known as instrumentation cables, are designed for process temperature measurement applications. These cables feature construction similar to pair instrumentation cables but utilize specialized conductor materials to match the thermoelectric properties of thermocouples used for temperature sensing and control systems.
Thermocouple Compensation Cable Types
Our manufacturing facility specializes in producing various thermocouple compensation wire types including KX, EX, JX, TX, SC/RC, KCA, and KCB. These products are manufactured in compliance with GB/T 4990-2010 (Chinese National Standard) and IEC584-3 (International Standard) specifications.
Compensation Wire Classification
X: Extension type - compensation wire alloy matches the thermocouple alloy composition
C: Compensation type - wire alloy exhibits similar characteristics to thermocouple alloy within specific temperature ranges
| Thermocouple Code |
Comp. Type |
Comp. Wire Name |
Positive |
Negative |
| S |
SC |
copper-constantan 0.6 |
copper SPC |
constantan 0.6 SNC |
| R |
RC |
copper-constantan 0.6 |
copper RPC |
constantan 0.6 RNC |
| K |
KCA |
Iron-constantan22 |
Iron KPCA |
constantan22 KNCA |
| K |
KCB |
copper-constantan 40 |
copper KPCB |
constantan 40 KNCB |
| K |
KX |
Chromel10-NiSi3 |
Chromel10 KPX |
NiSi3 KNX |
| N |
NC |
Iron-constantan 18 |
Iron NPC |
constantan 18 NNC |
| N |
NX |
NiCr14Si-NiSi4Mg |
NiCr14Si NPX |
NiSi4Mg NNX |
| E |
EX |
NiCr10-Constantan45 |
NiCr10 EPX |
Constantan45 ENX |
| J |
JX |
Iron-constantan 45 |
Iron JPX |
constantan 45 JNX |
| T |
TX |
copper-constantan 45 |
copper TPX |
constantan 45 TNX |
Material Specifications
Chemical Composition
| Material |
Ni |
Cr |
Si |
Mn |
Al |
| KP(Chromel) |
90 |
10 |
|
|
|
| KN(Alumel) |
95 |
|
1-2 |
0.5-1.5 |
1-1.5 |
Physical and Mechanical Properties
| Material |
Density (g/cm³) |
Melting Point (°C) |
Tensile Strength (MPa) |
Volume Resistivity (μΩ.cm) |
Elongation Rate (%) |
| KP(Chromel) |
8.5 |
1427 |
>490 |
70.6 (20°C) |
>10 |
| KN(Alumel) |
8.6 |
1399 |
>390 |
29.4 (20°C) |
>15 |
Product Specifications
Conductor: Flexible Bare Annealed Copper Wire
Insulation: Silicone
Jacket Colors: Black, Orange, Red, Yellow, Blue (single & double insulated)
SQ MM Sizes (European): 4 sq mm to 240 sq mm
AWG Sizes (North American): 0AWG-10AWG
Temperature Range: -60°C to 200°C
| Brand |
LINKE |
Cross Section (mm²) |
0.01-500mm² |
| Wire Gauge (AWG) |
[e.g., 24AWG, 28AWG] |
Conductor |
Tinned Copper /bare copper, based on client's requirements |
| Insulation material |
PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other |
Jacket Material |
[PVC/PU/Rubber/Braid/etc.] |
| Certifications |
RoHS/REACH/UL/CE/IP68/etc |
Custom Length |
[e.g., 1m, 3ft, 5m ±5% tolerance] |
| Cable Type |
[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] |
Shielding |
[Shielded/Unshielded/Braid Shield] |
| Impedance |
[e.g., 75Ω (for coaxial cables)] |
Printing/Logo |
[Text/Label/Logo, max. 20 characters] |
| Bend Radius |
[e.g., ≥5× cable diameter] |
Current Rating |
[e.g., 5A] |
| Voltage Rating |
[e.g., 30V AC/DC] |
Connector Material |
[Gold-plated/Nickel-plated/Brass/etc.] |
| Connectors |
[e.g., USB Type-C, 3.5mm Jack, RJ45] |
Jacket |
XLPE or PE or PVC RUBBER |
| Delivery Time |
7-14 days after confirming the order |
Colors |
[Black/White/Red/Custom Pantone/etc.] |
| temperature |
Minus-70℃to 350℃(-70℃ ~ 350℃) |
Package |
Roll/box/plate/Custom |
| Supporting Services |
custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated) |
Certifications and Standards
Our products meet multiple international standards including UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269, UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587, UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664, ISO9001, ISO13485, and TS16949.
