Customizable Multi Core Electrical Wire Cable Flexible Copper RVV Cable with 2 or 3 Cores

Copper Rvv Cable

3 Cores Rvv Cable

2Core Electrical Wire Cable

Place of Origin:

China

Brand Name:

LINKE CABLE

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Name:

Copper Wire

Application:

Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car

Voltage:

Low And Medium Voltage Cable

Customization:

Available

Conductor Material:

Copper/Tinned Copper

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Colour:

Customize

Type:

Insulated

Highlight:

Copper Rvv Cable

3 Cores Rvv Cable

2Core Electrical Wire Cable

Payment & Shipping Terms

Minimum Order Quantity

1000m

Price

Negotiable

Packaging Details

According to requirement

Delivery Time

7-15 days

Payment Terms

Advance 30% deposit and ship after receiving 70% final payment

Supply Ability

50000m/day

UL2468 PVC Insulation 2 Core Copper Speaker Wire Flexible Cable 300V Rated

Get Best Price

Electric Industrial Welding Wire 6AWG Rubber Sheathed Copper Cable with PVC Insulation

Get Best Price

Multi Core Flexible PVC Sheath Composite Access Control Cable Electrical Wire Cable New energy vehicle cable

Get Best Price

American Standard Industrial Cables Package Gross Weight 30.000kg UL Certificate YJLV22

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

Customized Multi Core Electrical Wire Cable

2 or 3 Cores Flexible Copper RVV Cable

Electrical Installation Cable (RVV)

Application

This cable is used as control and connecting cables for electrical equipment. It applies to machine tools and complete sets of equipment for fixed installation.

Cable Construction

Conductors: Flexible ultra-fine stranded copper wire
Insulation: Flexible heat resistant PVC
Insulation Colors:
- Two core: black, white
- Three core: blue, brown, yellow/green
- Four core: black, blue, brown, yellow/green
- Five core and above: black insulated wire with white font printing
Filler: Cotton or PP filler
Jacket: Flexible heat resistant PVC mixture
Product reference standard: GB/T5023; JB8734
Note: Cables having more than 3 cores contain yellow/green wire

Product Features

Good mechanical properties
Excellent electrical insulation capability and chemical resistance
Fire resistance meets IEC60332-1 standard

Cross Section

Technical Data

Temperature Range:
- Bend: -5℃ to +70℃
- Static: -15℃ to +70℃

Rated Voltage:
- CCC: 300/300V, 300/500V
- IEC/VDE < 1.5mm²: 300/300V
- IEC/VDE ≥ 1.5mm²: 300/500V

Test Voltage: ≥0.5mm² 2500V/5min
Insulation Resistance: 20℃ ≥ 10MΩ/km
Minimum Bending Radius:
- Fixed: 6D (D=cable diameter)
- Moving: 15D (D=cable diameter)

Torsion Angle: ±90°/m
Moving: ±90°/m

Product Specifications

Specification	Nominal OD (mm)	Copper Weight (kg/km)	Weight (kg/km)
RVV 2×0.5mm²	5.3	9	35
RVV 3×0.5mm²	5.6	14	45
RVV 4×0.5mm²	6.4	19	58
RVV 5×0.5mm²	6.9	23	68
RVV 10×0.5mm²	9.4	47	119
RVV 15×0.5mm²	11.4	70	188
RVV 20×0.5mm²	12.6	93	237
RVV 30×0.5mm²	14.7	140	331
RVV 2×0.75mm²	6.1	14	46
RVV 3×0.75mm²	6.5	21	61
RVV 4×0.75mm²	7.4	28	79
RVV 5×0.75mm²	8.0	35	93
RVV 10×0.75mm²	11.7	70	189
RVV 15×0.75mm²	13.3	105	260
RVV 20×0.75mm²	14.7	140	331
RVV 30×0.75mm²	17.2	209	467
RVV 2×1.0mm²	6.8	19	59
RVV 3×1.0mm²	7.2	28	78
RVV 4×1.0mm²	7.9	37	93
RVV 5×1.0mm²	8.6	47	111
RVV 10×1.0mm²	12.5	93	225
RVV 15×1.0mm²	14.3	140	311
RVV 20×1.0mm²	15.8	186	398
RVV 30×1.0mm²	20.7	279	664
RVV 2×1.5mm²	7.8	27	77
RVV 3×1.5mm²	8.3	41	103
RVV 4×1.5mm²	9.1	55	126
RVV 5×1.5mm²	10.6	68	171
RVV 10×1.5mm²	14.5	136	306
RVV 15×1.5mm²	16.6	205	428
RVV 20×1.5mm²	20.6	273	649
RVV 30×1.5mm²	23.9	409	903
RVV 2×2.5mm²	9.0	45	107
RVV 3×2.5mm²	9.6	67	146
RVV 4×2.5mm²	11.2	89	202
RVV 5×2.5mm²	12.2	111	242
RVV 10×2.5mm²	16.9	223	442
RVV 15×2.5mm²	21.6	334	729
RVV 20×2.5mm²	23.8	445	926
RVV 30×2.5mm²	27.8	668	1306

Standards & Compliance

The control cable can be produced according to the standard GB9330-1988, and we can also manufacture cables in accordance with other international standards.

Scope of Application

These control cables are suitable for electrical controlling equipment and instrument wiring, monitoring and controlling return circuits, electrical protection and measurement in power distribution units with rated voltage up to 450/750V AC.

Company Profile

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China. For over 10 years, Linke Cable has focused on R&D, production and marketing of wire and cable. We provide various cables and custom cable solutions worldwide, specializing in EV charging cable, medical cable, silicone cable, spring cable, braided cable, towlobe cable, UL wire, automotive cable, and more.

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from beginning to end. Welcome to visit us - we'll pick you up in Shenzhen.

How can I get a sample to test your quality?

Samples are free for you. New clients are expected to pay for courier costs.

What's your Minimum Order Quantity?

Normally 100m. However, cable is very heavy. We recommend ordering a suitable quantity to avoid high freight costs. Sea transportation is the best option.

Can I get a discount?

Discounts depend on your quantity. We can offer discounts and cover freight costs for larger orders. Please contact us for details.

Does your company accept OEM production?

Yes, we can print your company name and even customize quality cards to promote your company.
