Product Specifications
| Type |
XLPE Silicone CABLE |
|
| Cable grade |
-40ºC~+180ºC600V AC/1000V DC |
|
| Standard |
LV 216-1/ISO 6722 |
| Item |
SPEC mm²
(****) |
Conductor |
Insulated |
| Material |
Structure(mm) |
max twisted OD(mm) |
Material |
OD
(mm) |
mini thickness
(mm) |
Color |
20ºC conductor resistance mΩ/m) |
20ºC insulated cubic resistance rage |
| TEVB400-XX-275 |
4mm² |
Copper |
56/(0.30±0.008) |
2.80 |
Silicone |
4.20±0.20 |
0.64 |
Orange(RAL2003) Or Other Color custom |
≤4.70 |
>=10¹³Ω·mm |
| TEVB600-XX-545 |
6mm² |
84/(0.30±0.008) |
3.40 |
4.80±0.20 |
0.64 |
≤3.10 |
| TEVBA10-XX-198 |
10mm² |
323/(0.20±0.008) |
4.50 |
6.20±0.30 |
0.80 |
≤1.82 |
| TEVBA16-XX-246 |
16mm² |
512/(0.20±0.008) |
5.80 |
8.00±0.30 |
0.80 |
≤1.16 |
| TEVBA25-XX-191 |
25mm² |
790/(0.20±0.008) |
7.20 |
9.70±0.30 |
1.04 |
≤0.743 |
| TEVBA35-XX-273 |
35mm² |
1090/(0.20±0.008) |
8.50 |
10.65±0.35 |
1.04 |
≤0.527 |
| TEVBA50-XX-246 |
50mm² |
1600/(0.20±0.008) |
10.50 |
12.80±0.40 |
1.20 |
≤0.368 |
| TEVBA70-XX-275 |
70mm² |
2175/(0.20±0.008) |
12.50 |
14.70±0.40 |
1.20 |
≤0.259 |
| TEVBA95-XX-069 |
95mm² |
3000/(0.20±0.008) |
14.80 |
16.90±0.50 |
1.28 |
≤0.196 |
| TEVBA120-XX-058 |
120mm² |
3700/(0.20±0.008) |
16.50 |
19.00±0.50 |
1.28 |
≤0.153 |
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double
insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
Certifications & Standards
We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269
(Single conductor,thermoplastic insulation)
UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,
UL2587,UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664
ISO9001 and ISO13485,TS16949
CNR- Appliance Wiring Material,
Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1
and/or FT2.
Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class
or Class I/Il, Group A, B, or AB, FT1 and/or FT2.
Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class
or Class I/Il, Group A, B, or AB, FT1 and/or FT2
FAQ
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first
begining to the last.
Welcome to visit us. We'll pick you up in Shenzhen.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier
cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a
suitable quantity to avoid the high freight.
Sea transportation is the
best option.
4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls
kindly contact us.
5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote
your company.
For More Information, Please do feel free to contact us!
