| Product Name |
Custom wire harness assembly |
| Cable Material |
Cable can be U-L/VDE/CCC/CSA/PSE etc and pure copper |
| AWG |
Customized |
| Color |
Customized |
| Length |
Customized |
| Insulation |
Customized/Rubber,Silicone,PE,PVC etc |
| Connector Type |
Original OEM or Replacement |
| Test |
Pulling force test and continuity test |
| Application |
Electronics, small household appliances, automotive, industrial and other industries |
| Certificate |
RoHS/ISO/U-L etc |
| Service |
OEM and ODM products are acceptable |
| Order Quantity |
Small quantity can be accepted, like 100pcs |
| Samples |
Samples confirmed first before mass production |
| Delivery Time |
3-7days for samples,10-30days for batch goods/ negotiable |
| Package |
PE Bag/Paper Box/Customized |
| Shipping |
DHL/TNT/UPS/EMS/SF for samples etc/negotiable |
| Payment |
T/T,L/C,Western,PayPal,XTransfer etc |
| Company Advantage |
1.Professional wire harness manufacturer for automotive, home appliance, Electronic, industrial control, Security Equipment, USB, medical and so on
2. Our factory starts production from 2015 years with years of production experience in this trade.
3. We accept ODM/OEM design, welcome any customized cable too, whenever you have demand, we will reply to you fastly and quote you the best prices we can.
4. Our wire can be U-L/VDE/CCC/CSA/PSE certificates, Rohs and so on.
5. Our factory has got ISO9001 certificates. Strict quality control, All the products are 100% test before delivery.
6. We have a perfect after-sales service process to ensure that you can still get good service after receiving the goods
|
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :10 sq mm to 240 sq mm
AWG sizes (North American style) :6 Awg to 50awg
Wide temperature range: -60°C to 200°C
| Brand |
LINKE |
Cross Section (mm²) |
0.01-500mm² |
| Wire Gauge (AWG) |
[e.g., 24AWG, 28AWG] |
Conductor |
Tinned Copper /bare copper, based on client's requirements |
| Insulation material |
PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other |
Jacket Material |
[PVC/PU/Rubber/Braid/etc.] |
| Certifications |
RoHS/REACH/UL/CE/IP68/etc |
Custom Length |
[e.g., 1m, 3ft, 5m ±5% tolerance] |
| Cable Type |
[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] |
Shielding |
[Shielded/Unshielded/Braid Shield] |
| Impedance |
[e.g., 75Ω (for coaxial cables)] |
Printing/Logo |
[Text/Label/Logo, max. 20 characters] |
| Bend Radius |
[e.g., ≥5× cable diameter] |
Current Rating |
[e.g., 5A] |
| Voltage Rating |
[e.g., 30V AC/DC] |
Connector Material |
[Gold-plated/Nickel-plated/Brass/etc.] |
| Connectors |
[e.g., USB Type-C, 3.5mm Jack, RJ45] |
Jacket |
XLPE or PE or PVC RUBBER |
| Delivery Time |
7-14 days after confirming the order |
Colors |
[Black/White/Red/Custom Pantone/etc.] |
| temperature |
Minus-70℃to 350℃(-70℃ ~ 350℃) |
Package |
Roll/box/plate/Custom |
| Supporting Services |
custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated) |
We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269
(Single conductor,thermoplastic insulation)
UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664
ISO9001 and ISO13485,TS16949
CNR- Appliance Wiring Material,
Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.
Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.
Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2
FAQ
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.
Welcome to visit us. We'll pick you up in Shenzhen.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.
4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.
5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
