Place of Origin:
Dongguan
Brand Name:
linkecable
Certification:
3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949
Video
Polyurethane Wire & Cable TPU wire&Cable
UL Style Number:20233
Specifications
Rated voltage: 300V
Rated Temperature: 80℃
Standard: UL758/UL1581
Applications
Internal wiring or external interconnection of electronic equipment.
印字Marking:E364879 AWM 20233 **AWG VW-1 80℃ 300V C AWM I A 80℃ 300V FT1 Linke Cable
| Conductor | Insulation | Core |
Shield
|
Jacket |
Max. Conductor Resistance (Ω/KM) |
|||||
|
Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal thickness (mm) |
Diameter (mm) |
Optional |
Shield Rate (%) |
Nominal thickness(mm) |
Diameter (mm) |
Bare copper |
Tinned copper |
| 26 | 7/0.16 | 0.48 | 0.23 | 1.00±0.10 | 2 | Optional | 0.76 | 3.50±0.10 | 140 | 150 |
| 3 | 3.70±0.15 | |||||||||
| 4 | 3.90±0.15 | |||||||||
| 24 | 7/0.20 | 0.60 | 0.23 | 1.10±0.10 | 2 | Optional | 0.76 | 3.70±0.15 | 87.6 | 94.2 |
| 3 | 3.90±0.15 | |||||||||
| 4 | 4.20±0.15 | |||||||||
| 22 | 7/0.254 | 0.78 | 0.23 | 1.30±0.10 | 2 | Optional | 0.76 | 4.10±0.15 | 55.4 | 59.4 |
| 3 | 4.30±0.15 | |||||||||
| 4 | 4.70±0.15 | |||||||||
| 20 | 26/0.16 | 0.94 | 0.23 | 1.50±0.10 | 2 | Optional | 0.76 | 4.50±0.15 | 34.6 | 36.7 |
| 3 | 4.80±0.15 | |||||||||
| 4 | 5.10±0.15 | |||||||||
| 18 | 41/0.16 | 1.18 | 0.23 | 1.80±0.10 | 2 | Optional | 0.76 | 5.10±0.15 | 21.8 | 23.2 |
| 3 | 5.40±0.15 | |||||||||
| 4 | 5.90±0.15 | |||||||||
| 16 | 26/0.254 | 1.49 | 0.23 | 2.10±0.10 | 2 | Optional | 0.76 | 5.70±0.15 | 13.7 | 14.6 |
| 3 | 6.00±0.15 | |||||||||
| 4 | 6.60±0.15 | |||||||||
Note: Wire specifications can be customized
Colours:(Black),(Brown),(Red),(Orange),(Yellow),(Green),(Blue),(Purple),(Gray),(White),(Yellow/Green),(Transparent)
Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.
In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing
of wire and cable. Linke provide various cables&custom cable solutions for all over the world.
We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,
towlobe cable, UL wire, automotive cable, etc.
At Linke cable, we believe there's a better way to bring better cables to market. We use an
engineer-to-engineer approach to develop better cables for customers and improve the quality
of one's life.
| Single-conductor, thermoplastic insulation | |||||||
| 1007 | 1330 | 1333 | 1591 | 1723 | 10064 | 10369 | |
| 1015 | 1331 | 1569 | 1592 | 1901 | 10070 | 10483 | |
| 1185 | 1332 | 1577 | 1672 | 10012 | 10269 | ||
| Multiple-conductor, thermoplastic insulation | |||||||
| 2095 | 2129 | 2468 | 2586 | 2725 | 20233 | 20280 | 20963 |
| 2103 | 2463 | 2517 | 2587 | 2835 | 20276 | 20549 | 21198 |
| 2104 | 2464 | 2576 | 2661 | 2919 | 20279 | 20886 | 21664 |
| Single-conductor, thermoset insulation | |||||||
| 3075 | 3173 | 3320 | 3386 | 3530 | 3689 | 30005 | |
| 3123 | 3212 | 3321 | 3398 | 3577 | 3702 | ||
| 3132 | 3266 | 3331 | 3512 | 3644 | 3817 | ||
| 3135 | 3271 | 3385 | 3529 | 3674 | 3886 | ||
1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.
Welcome to visit us. We'll pick you up in Shenzhen.
2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.
4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.
5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.
For More Information, Please do feel free to contact us!
