| Product Item |
UL1332 Cable |
| Country of Origin |
China |
| Production Specification |
According to customer requirements |
| Insulation Material |
FEP |
| Rated Tempature |
200°C |
| Color |
Yellow, Green, Black, Red, Grey, Brown, Blue, Qrange, White and Transparent |
| Rated Voltage(U0/U) |
300V |
FEP/ETFE/PFA/PTFE Wire&Cable
UL Style Number:1332
Specifications
Rated voltage: 300V
Rated Temperature: 200℃
Standard: UL758/UL1581
Applications
Widely used in home appliance, lighting, heater, motor &generator, UAV, robot, industrial power etc.
Marking:E364879
AWM 1332 **AWG VW-1 200℃ 300V C AWM I A 200℃ 300V FT1 Linke Cable
Note: Wire specifications can be customized
| 导体Conductor |
绝缘Insulation |
最大导体电阻 Max.
Conductor Resistance(Ω/KM)
|
|
线规
Size(AWG)
|
线数/线径
Construction(No./mm)
|
直径
Diameter(mm)
|
绝缘厚度
Nominal thickness(mm)
|
完成外径
Diameter(mm)
|
裸铜
Bare copper
|
镀锡铜
Tinned copper
|
| 30 |
7/0.10 |
0.30 |
0.33 |
1.00±0.05 |
354 |
381 |
| 28 |
7/0.127 |
0.38 |
0.33 |
1.05±0.05 |
223 |
239 |
| 26 |
7/0.16 |
0.48 |
0.33 |
1.15±0.05 |
140 |
150 |
| 24 |
7/0.20 |
0.60 |
0.33 |
1.25±0.05 |
87.6 |
94.2 |
| 22 |
7/0.254 |
0.78 |
0.33 |
1.45±0.10 |
55.4 |
59.4 |
| 20 |
26/0.16 |
0.94 |
0.33 |
1.60±0.10 |
34.6 |
36.7 |
| 18 |
41/0.16 |
1.18 |
0.33 |
1.85±0.10 |
21.8 |
23.2 |
| 16 |
26/0.254 |
1.49 |
0.33 |
2.15±0.10 |
13.7 |
14.6 |
| 14 |
41/0.254 |
1.88 |
0.33 |
2.55±0.10 |
8.62 |
8.96 |
| 12 |
65/0.254 |
2.36 |
0.33 |
3.05±0.10 |
5.43 |
5.64 |
| 10 |
105/0.254 |
3.00 |
0.33 |
3.70±0.15 |
3.409 |
3.546 |
| Brand |
LINKE |
Cross Section (mm²) |
0.01-500mm² |
| Wire Gauge (AWG) |
[e.g., 24AWG, 28AWG] |
Conductor |
Tinned Copper /bare copper, based on client's requirements |
| Insulation material |
PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other |
Jacket Material |
[PVC/PU/Rubber/Braid/etc.] |
| Certifications |
RoHS/REACH/UL/CE/IP68/etc |
Custom Length |
[e.g., 1m, 3ft, 5m ±5% tolerance] |
| Cable Type |
[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.] |
Shielding |
[Shielded/Unshielded/Braid Shield] |
| Impedance |
[e.g., 75Ω (for coaxial cables)] |
Printing/Logo |
[Text/Label/Logo, max. 20 characters] |
| Bend Radius |
[e.g., ≥5× cable diameter] |
Current Rating |
[e.g., 5A] |
| Voltage Rating |
[e.g., 30V AC/DC] |
Connector Material |
[Gold-plated/Nickel-plated/Brass/etc.] |
| Connectors |
[e.g., USB Type-C, 3.5mm Jack, RJ45] |
Jacket |
XLPE or PE or PVC RUBBER |
| Delivery Time |
7-14 days after confirming the order |
Colors |
[Black/White/Red/Custom Pantone/etc.] |
| temperature |
Minus-70℃to 350℃(-70℃ ~ 350℃) |
Package |
Roll/box/plate/Custom |
| Supporting Services |
custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated) |
Company Profile
Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.
In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of
wire and cable. Linke provide various cables&custom cable solutions for all over the world.
We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,
towlobe cable, UL wire, automotive cable, etc.
At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-
engineer approach to develop better cables for customers and improve the quality of one's life.
Quality Certifications
Our products meet the following international standards:
UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587
UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
ISO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
