Fire Resistant PVC Insulated Electrical Wire 18AWG UL1185 Power Signal Cable

Fire Resistant Electrical Wire 18AWG

Fire Resistant Electrical Wire 300V

UL1185 Power Signal Cable

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Model NO.:

UL1185

Conductor Material:

Copper

Sheath Material:

PVC

Material Shape:

Round Wire

Conductor Type:

Twisted Wire

payment Method:

Initial Payment Full Payment

Core:

Multiple

Conductor Material:

Copper/Tinned Copper

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Rated Temperature:

-60± 200℃

Highlight:

Fire Resistant Electrical Wire 18AWG

Fire Resistant Electrical Wire 300V

UL1185 Power Signal Cable

Payment & Shipping Terms

Minimum Order Quantity

1000m

Price

Negotiable

Packaging Details

Safe packaging

Delivery Time

7-15 days

Payment Terms

Advance payment+final payment upon shipment

Supply Ability

50000m/day

1-30AWG Tinned Copper XLPE Insulation UL1015 Control Cable for Industrial Applications

Get Best Price

Video

FEP Insulated UL1333 Cable with Oil Resistance and Wide Temperature Range for Temperature Sensors

Get Best Price

Video

Flexible Electric Cable with Pure Copper Conductor 450/750V PVC Insulation UL Electrical Wire

Get Best Price

Video

Oil Resistant PVC Outer Jacket Shielded Wire Data Cable with High-speed Transmission for Electronic Equipment

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

PVC Insulated Fire Resistant Electrical Wire 18AWG 300V Power Signal Cable

UL1185 Single-Core Insulated Wire Specifications

Rated temperature: 80°C
Rated voltage: 300 volts
Conductors: 30-4/0 AWG solid or stranded bare or tinned copper wire
Lead-free PVC insulation
Bare or tinned copper wire wrapped for shielding
Lead-free PVC coating, compliant with RoHS regulations
Passed UL VW-1 vertical flame resistance test
Reference standards: UL 758 and UL 1581

Application

Internal wiring of general electronic and electrical equipment

Construction Specifications

P/N	Conductor AWG	Conductor No./mm	Insulation Material	Insulation Thickness/mm	Spiral Shield No./mm	Jacket Material	Jacket Thickness/mm	Overall Diameter/mm
1185-22	22	17/0.160	PVC	0.38	42/0.12	PVC	0.38	2.70
1185-20	20	21/0.180	PVC	0.38	47/0.12	PVC	0.38	2.90
1185-18	18	34/0.180	PVC	0.38	55/0.12	PVC	0.38	3.15
1185-16	16	26/0.254	PVC	0.38	61/0.12	PVC	0.38	3.50

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

Can I get a discount?

It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.

Does your company accept OEM production?

Yes, we can print your company name, and we even customize the quality card to promote your company.
