Wurth Elektronik RG142 Coaxial Cable with 50 Ω Impedance and 4.95mm OD SMA Male to SMA Male for New Energy Vehicles

Twisted Electric Guitar Cable

Braided Woven Fabric Electric Guitar Cable

Coaxial Round Twisted Electric Guitar Cable

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Model NO.:

LK-M03

Species:

HDMI

Material Shape:

Round Wire

Wire Core Material:

Tinned Wire

Name:

Music Cable

Jacket:

PVC, PE

Conductor:

Tinned Copper

Insulation:

Ethylene-Propylene Rubber Mixture Or Elastomer

Application:

Multimedia, DVD Player, Speaker, Monitor, Microphone, Guitar

Color:

Brown

Type:

Coaxial

Customization:

Available

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Core:

Multiple

Conductor Material:

Copper/Tinned Copper

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Rated Voltage:

300-600V

Rated Temperature:

-60± 200℃

Type:

Insulated

Package:

By Roll

Lead Time:

7-15days

Highlight:

Twisted Electric Guitar Cable

Braided Woven Fabric Electric Guitar Cable

Coaxial Round Twisted Electric Guitar Cable

Payment & Shipping Terms

Minimum Order Quantity

1000m

Price

Negotiable

Packaging Details

According to requirement

Delivery Time

7-15day

Payment Terms

Advance 30% deposit and ship after receiving 70% final payment

Supply Ability

50000m/day

Wholesale New Energy Flexible Power Cable with Copper Conductor and XLPE Insulation for Customizable PVC Jacket

Get Best Price

Video

Customized 1200A Flexible Busbar with 0.1mm Copper Foil for Substation Engineering

Get Best Price

Video

Tinned Copper Conductor Elevator Cable with PVC Insulation and Customizable Jacket for Power and Control Applications

Get Best Price

Video

Round Wire Elevator Cable with Tinned Copper Conductor and PVC Insulation for Various Elevators

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

Wurth Elektronik RG142 Coaxial Cable 50 Ω

SMA male to SMA male white coaxial cable designed for new energy vehicle applications with 4.95mm outer diameter.

Cable Specifications

Property	Value	Unit
Cable Type	RG-142U	-
Nominal Outer Diameter	4.95	mm
Impedance	50	Ω

Connector Specifications

Connector 1 (Straight)

Component	Material	Plating/Color
Insulator	PTFE	White
Center Contact	Brass	Gold, min. 0.76μm over Nickel
Body	Brass	Gold, min. 0.076μm over Nickel
Coupling Nut	Brass	Gold, min. 0.076μm over Nickel
Retention Ring	Stainless Steel	Passivated
Gasket	Silicone	Red
Ferrule	Brass	Gold, min. 0.076μm over Nickel
Heat Shrink Tube	PE	Black

Connector 2 (Right Angle)

Component	Material	Plating/Color
Insulator	PTFE	White
Center Contact	Brass	Gold, min. 0.76μm over Nickel
Body	Brass	Gold, min. 0.076μm over Nickel
Coupling Nut	Brass	Gold, min. 0.076μm over Nickel
Retention Ring	Stainless Steel	Passivated
Gasket	Silicone	Red
Ferrule	Brass	Gold, min. 0.076μm over Nickel
Cover	Brass	Gold, min. 0.076μm over Nickel
Heat Shrink Tube	PE	Black

Electrical Properties

Property	Test Conditions	Value	Unit	Tolerance
Frequency Range	DC-6 GHz	DC-6 GHz	-	-
VSWR	DC-6 GHz	1.5	-	Max.
Insertion Loss	DC-6 GHz	0.48	dB	Max.
Insulation Resistance	500 V DC in 120 sec.	5000	MΩ	Min.
Withstanding Voltage	500 V AC in 60 sec.	1000	V(RMS)	Min.
Working Voltage	-	335	V(RMS)	Min.

General Information

Property	Value
Operating Temperature	-55°C to +165°C
Compliance	RoHS
Interface	ML-STD-348
Cable Type	Flexible
Cable Shielding	Braid
Connector Type	SMA to SMA
Gender	Male to Male
Orientation	Straight to Right Angle

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

Can I get a discount?

It depends on your quantity. We can make a discount and afford the freight. Please kindly contact us.

Does your company accept OEM production?

Yes, we can print your company name, and we even custom the quality card to promote your company.
