Home > Products > Automotive Wire Cable >

AVS Automotive PVC Insulated Copper Wire Cable 1200A Customized High Temperature Resistance

PVC Insulated Copper Wire

1200A PVC Insulated Copper Wire

Copper Wire and Cable 1200A

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Model NO.:

AV AVS

AMP:

1200A

Color:

Customized

Customized:

Customized

Material:

Silicone

Conductor:

Tinned Copper

Insulation:

Silicone

Jacket:

Silicone

Voltage:

500V

Property:

High Temperature Resistance

Transport Package:

Box Packaging

Specification:

60*60*50CM

Trademark:

LINKE

Origin:

China

HS Code:

94054090

Supply Ability:

100000000

Package Size:

83.00cm * 83.00cm * 58.00cm

Package Gross Weight:

28.000kg

Lead Time:

7-15days

After-sales Service:

1year

Warranty:

1year

Certification:

RoHS, TUV, CE, ISO

Customization:

Available

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Core:

Multiple

Conductor Material:

Copper/Tinned Copper

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Rated Voltage:

300-600V

Rated Temperature:

-60± 200℃

Colour:

Customize

Type:

Insulated

Package:

By Roll

Currency:

US$

Highlight:

PVC Insulated Copper Wire

1200A PVC Insulated Copper Wire

Copper Wire and Cable 1200A

Payment & Shipping Terms

Minimum Order Quantity

3000m

Price

Negotiable

Packaging Details

According to requirement

Delivery Time

7-15 days

Payment Terms

Advance 30% deposit and ship after receiving 70% final payment

Supply Ability

50000m/day

Elevator Control Cable with Power Cable PVC Insulated Tinned Copper for Low and Medium Voltage Applications

Get Best Price

Video

Tinned Copper Elevator Cable Flexible PVC Traveling Cable 300V Rated for Construction and Industrial Use

Get Best Price

Video

Wurth Elektronik RG142 Coaxial Cable with 50 Ω Impedance and 4.95mm OD SMA Male to SMA Male for New Energy Vehicles

Get Best Price

Video

Premium High Voltage 380V EV Wire Harness with Bare Copper Conductor and Rubber Jacket for Electric Vehicles

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

AVS Automotive PVC Insulated Copper Wire and Cable Customized 1200A

Product Overview

AV type Automotive PVC insulated single-core cable designed for low voltage circuits in automobiles, vehicles, and motorcycles. Ideal for starting, charging, lighting, signal, and instrument panel circuits.

Key Specifications

Brand	LINKE Cable
Conductor	Copper
Core	Single Core
Available Colors	Black, Blue, Brown, Dark Blue, Gray, Green, Orange, Purple, Red, White, Yellow (Customized options available)
Temperature Range	-40°C to +85°C
Nominal Voltage	60V
Minimum Order Quantity	300M/Roll

Applications

Low voltage circuits in automobiles, vehicles, and motorcycles
General purpose automotive wiring
Starting, charging, lighting, signal, and instrument panel circuits

Product Features

Stranded copper conductor (0.3 - 5.0 SQMM)
Soft-annealed electrolytic copper Cu-ETP1 conductor
PVC insulation, lead-free
Compliant with JIS C 3406 and JASO D 611 standards
Meter marking packaging

Technical Specifications - AV/AVF Series

Nominal cross-section (mm²)	No. of strands	Dia. Single Wire Max. (mm)	Dia. Conductor Max. (mm)	Elec. Resistance at 20°C (mΩ/m)	Wall Thickness (mm)	O.D. Min (mm)	O.D. Max (mm)
0.5	7	0.32	1.0	32.7	0.6	2.2	2.4
0.85	11	0.32	1.2	20.8	0.6	2.4	2.6
1.25	16	0.32	1.5	14.3	0.6	2.7	2.9
2	26	0.32	1.9	8.81	0.6	3.1	3.4
3	41	0.32	2.4	5.59	0.7	3.8	4.1
5	65	0.32	3.0	3.52	0.8	4.6	4.9
8	50	0.45	3.7	2.32	0.9	5.5	5.8
10	63	0.45	4.5	1.84	1.0	6.5	6.9
15	84	0.45	4.8	1.38	1.1	7.0	7.4

Company Capabilities

We maintain a strong R&D team with 6 engineering professionals, each possessing over 10 years of expertise in wire and cable technology. Our quality control department includes 10 specialists who rigorously supervise every step from incoming materials to shipping, ensuring 100% product quality. With more than 50 experienced production staff, we deliver reliable automotive wire solutions.

AVS Automotive PVC Insulated Copper Wire Cable 1200A Customized High Temperature Resistance

Brand	LINKE	Cross Section (mm²)	0.01-500mm²
Wire Gauge (AWG)	[e.g., 24AWG, 28AWG]	Conductor	Tinned Copper /bare copper, based on client's requirements
Insulation material	PVC/TPU/Silicone rubber/PE/PP/XLPE/Nylon/other	Jacket Material	[PVC/PU/Rubber/Braid/etc.]
Certifications	RoHS/REACH/UL/CE/IP68/etc	Custom Length	[e.g., 1m, 3ft, 5m ±5% tolerance]
Cable Type	[Medical/Power/Audio/Coaxial/Electrical/Automotive/Energy storage//etc.]	Shielding	[Shielded/Unshielded/Braid Shield]
Impedance	[e.g., 75Ω (for coaxial cables)]	Printing/Logo	[Text/Label/Logo, max. 20 characters]
Bend Radius	[e.g., ≥5× cable diameter]	Current Rating	[e.g., 5A]
Voltage Rating	[e.g., 30V AC/DC]	Connector Material	[Gold-plated/Nickel-plated/Brass/etc.]
Connectors	[e.g., USB Type-C, 3.5mm Jack, RJ45]	Jacket	XLPE or PE or PVC RUBBER
Delivery Time	7-14 days after confirming the order	Colors	[Black/White/Red/Custom Pantone/etc.]
temperature	Minus-70℃to 350℃(-70℃ ~ 350℃)	Package	Roll/box/plate/Custom
Supporting Services	custom cable, end to end solutions, including precise cutting, crimping and installation of lugs (specify material,e.g.,copper/nickel plated)

Quality Certifications

Our products meet the following international standards:
UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587
UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
ISO9001 and ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105°C, 1000V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2
Extruded TPU Non-integral Jacketed Cable, rated 80°C, 300V, Class I, Class or Class I/II, Group A, B, or AB, FT1 and/or FT2

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer. We control your order from beginning to end. Welcome to visit us - we'll provide pickup service in Shenzhen.

How can I get a sample to test your quality?

Samples are free for evaluation. New clients are expected to pay for courier costs.

What's your Minimum Order Quantity?

Normally 100m. However, cable is heavy so we recommend ordering suitable quantities to avoid high freight costs. Sea transportation is the best option.

Can I get a discount?

Discounts depend on your order quantity. We can offer competitive pricing and freight arrangements. Please contact us for details.

Does your company accept OEM production?

Yes, we can print your company name and even customize quality cards to promote your brand.

For More Information

Please feel free to contact us for technical specifications, pricing, and custom solutions!
