Heat Resistant Silicone Cable with Multiple Core 0.5mm Flexible Silicone Wire for High Temperature Applications

Silicone Heat Resistant Wire

Silicone Insulated Cable 0.5mm

Silicone Heat Resistant Insulated Cable

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Model NO.:

Silicone Cable

Insulation Material:

Silicone

Material Shape:

Round Wire

Wire Core Material:

Tinned Wire

Copper:

Tinned Copper

Core:

Multiple

Application:

Construction, Overhead, Underground, Industrial, Power Station, Telecommunication, Computer, Car, Construction, Power Plant, Underground, Industrial

Voltage:

Low And Medium Voltage Cable

Customization:

Available

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Conductor Material:

Copper/Tinned Copper

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Rated Voltage:

300-600V

Rated Temperature:

-60± 200℃

Colour:

Customize

Type:

Insulated

Highlight:

Silicone Heat Resistant Wire

Silicone Insulated Cable 0.5mm

Silicone Heat Resistant Insulated Cable

Payment & Shipping Terms

Minimum Order Quantity

1000 m

Price

Negotiable

Packaging Details

According to requirement

Delivery Time

7-15 days

Payment Terms

Advance 30% deposit and ship after receiving 70% final payment

Supply Ability

50000m/day

Waterproof Flexible Silicone Rubber Cable with High Temperature Resistance for Industrial Applications

Get Best Price

Video

Wear Resistant High Flexibility Silicone Insulated Copper Cable with High Temperature Resistance for Electrical Installations

Get Best Price

Video

Heat Resistant Silicone Cable with Multiple Core 0.5mm Flexible Silicone Wire for High Temperature Applications

Get Best Price

Video

Signal Wiring Harness Cable Assembly for Custom Automotive Wire Harness Manufacturing New energy charging pile

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

Silicone Flexible Heat Resistant Wire Insulated Cable 0.5mm With Multiple Core Soft Silicone Wire

Applications

Silicone wire and cable are designed for applications requiring high flexibility and high temperature resistance. They serve as ideal connection cables for home appliances and high voltage equipment including transformers, generators, motors, and traction machines.

Key Characteristics

Excellent flexibility and high temperature resistance from -55℃ to +180℃
Superior dielectric strength using high-grade corona resistant silicone rubber insulation

Cable Structure

Conductor: Tinned copper, silver, or nickel copper
Insulator: Silicone rubber
Rated Temperature: -60℃ to +200℃
Rated Voltage: 300/500V
Available Colors: White, blue, red, black, brown, yellow, green, transparent, yellow/green

Mechanical Properties

Tensile Strength: 5N/mm² minimum
Elongation at Break: ≥150%
Minimum Bending Radius: 5×OD

Product Advantages

Our high temperature silicone cables offer exceptional flexibility and temperature resistance from -55ºC to 180ºC. The silicone rubber insulation provides excellent dielectric strength, while the braided synthetic yarn covering offers mechanical protection while maintaining flexibility. The varnished braiding provides excellent antifriction properties, abrasion resistance, and chemical resistance against transformer oil, fuel oil, and cleaning agents. In fire conditions, no corrosive or toxic gases are emitted, minimizing fire-related damage.

Quality Commitment

As a leading cable manufacturer, we prioritize quality above all. Our silicone rubber cables are produced in strict compliance with international standards, ensuring reliable performance and worldwide popularity. We guarantee qualified products for all our customers.

Common Applications

Silicone insulated wire is primarily used for household appliances, motors, and electric heating equipment. It offers excellent aging resistance, flexibility, and long service life, making it ideal as heat-resistant silicone cable.

Technical Specifications

AWG Size	Conductor Structure	Conductor OD (mm)	Insulation Thickness (mm)	Cable OD (mm)	Resistance (Ω/KM Max)
16	7/0.49	1.55	1.28	4.5	14.6
15	33/0.254	1.75	1.28	4.7	11.3
14	41/0.254	1.95	1.28	4.9	8.96
13	52/0.254	2.15	1.28	5.1	7.1
12	65/0.254	2.5	1.28	5.5	5.64
11	83/0.254	2.74	1.28	5.7	4.48
10	35/0.45	3.2	1.28	6.2	3.55
9	53/0.40	3.98	1.28	7.0	2.81
8	70/0.40	4.4	1.28	7.4	2.3
7	84/0.40	4.6	1.28	7.7	1.79
6	105/0.40	5.3	1.28	8.4	1.42
5	133/0.40	6.0	1.28	9.1	1.12
4	168/0.40	6.8	1.28	10.0	0.89
3	210/0.40	7.6	1.28	10.8	0.707
2	266/0.40	8.5	1.28	11.7	0.56
1	217/0.50	9.6	1.28	13.3	0.449

Certifications & Standards

UL Standards: UL1007, UL1185, UL1672, UL10070, UL10483, UL1015, UL1569, UL10012, UL10269 (Single conductor, thermoplastic insulation)
Additional UL Standards: UL2095, UL2129, UL2468, UL2586, UL2725, UL20233, UL20280, UL20963, UL2103, UL2463, UL2517, UL2587, UL2835, UL20276, UL20549, UL21198, 2104, UL2464, UL2576, UL2661, UL2919, UL20279, UL20886, UL21664
Quality Management: ISO9001, ISO13485, TS16949
CNR - Appliance Wiring Material
Extruded PVC Insulated Single, rated 105ºC, 1000V, Class I, Group A, B, or AB, FT1 and/or FT2
Extruded PVC Non-integral Jacketed Cable, rated 105ºC, 1000V
Extruded TPU Non-integral Jacketed Cable, rated 80ºC, 300V

Frequently Asked Questions

Are you a manufacturer or trading company?

We are a professional manufacturer managing your order from initial production to final delivery. We welcome visits to our facility and provide pickup service in Shenzhen.

How can I get a sample to test your quality?

Samples are provided free of charge. New customers are responsible for courier costs.

What's your Minimum Order Quantity?

Minimum order quantity is normally 100m. Due to the cable's weight, we recommend ordering suitable quantities to minimize freight costs. Sea transportation is the most economical option.

Can I get a discount?

Discounts are available based on order quantity. We may also cover freight costs for larger orders. Please contact us for details.

Does your company accept OEM production?

Yes, we offer OEM services including printing your company name and custom quality cards to promote your brand.

For More Information

Please feel free to contact us for detailed specifications, pricing, and custom requirements.
