Premium Silicone Rubber Cable with 300V Voltage and 0.1-450mm² Specifications for 300-600V Rated Voltage Applications

Unshielded Silicone Insulation Electric Wire

300V Silicone Insulation Electric Wire

High Voltage Silicone Insulation Electric Wire

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Request A Quote

Product Details

Model NO.:

LK-SC001

AMP:

1200A

Color:

Customized

Material:

Silicone

Conductor:

Tinned Copper

Voltage:

300V

Transport Package:

Roll

Specification:

80*80*60

Lead Time:

7-15days

Certification:

RoHS, TUV, CE, ISO

Samples:

US$ 1000/PCS 1 PCS(Min.Order) |

Customization:

Available

Shipping Cost:

About Shipping Cost And Estimated Delivery Time.

Return&refunds:

You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.

Core:

Multiple

Conductor Type:

Twisted Wire

Exterior Material:

Customize：PVC、PE、LSFOH、silicone Rubber

Insulating Materials:

Customize:PVC、PE 、XLPE、EPR、SIR

Specifications:

0.1-450mm²

Rated Voltage:

300-600V

Rated Temperature:

-60± 200℃

Highlight:

Unshielded Silicone Insulation Electric Wire

300V Silicone Insulation Electric Wire

High Voltage Silicone Insulation Electric Wire

Payment & Shipping Terms

Minimum Order Quantity

1000m

Price

US$0.20

Packaging Details

According to requirement

Delivery Time

7-15 days

Payment Terms

Advance 30% deposit and ship after receiving 70% final payment

Supply Ability

50000m/day

Industrial Control Cable for High-Temperature Applications with Silicone Rubber Wire Cable

Get Best Price

Flexible Silicone Cable 18 AWG High Voltage 3kv Tinned Copper Wire for Flexible Cable

Get Best Price

Unsheild Liquid Rubber Silicone USB Cable For Electrical Appliances

Get Best Price

Video

1500V Al-Mylar Shielded Customizable EV Charging Cable with Silicone Rubber Insulation

Get Best Price

86-0769-81776230

86-18665106395

sales@linkecable.com

Contact Now

Product Description

Premium Silicone Rubber Electrical Cables for Reliable Performance

Premium Silicone Rubber Cable with 300V Voltage and 0.1-450mm² Specifications for 300-600V Rated Voltage Applications 0

Silicone rubber cable, also known as AGR cable, is a type of wire made from high-quality silicone rubber material. With a working temperature range of approximately -60 to 200 degrees Celsius, silicone rubber cables are highly versatile and can be used in a wide range of applications. These cables are available in a variety of colors, including red, yellow, blue, white, black, and yellow-green.

Product Specifications

Product Range	Automotive wire harness, Appliance wire harness, Robot wire harness, Medical wire harness, etc.
Test	Professional breakover and pulling force test before shipment
Cable materials	Wire harness can be UL/CSA, CE, etc and pure copper
Cable color, length	According to the customers' requirements
Insulation	Rubber, Silicon, PE, etc.
Connector and Terminal Type	Original OEM or Replacement
Application	Automotive, Appliance equipment, Medical equipment, etc.
MOQ	1000PCS
Samples	Samples confirmed first before mass production
Certificates	ISO9001-2015, IATF16949-2016, CE, RoHS, SGS, TUV
Lead time	10-20 days
Service	OEM and ODM, we accept customization according to your requirement
Nominal Voltage	300V, 300/500V, 600V, 30V, 450/750V etc.
Temperature Range	-30ºC~+80ºC, -30ºC~+90ºC, -30ºC~+105ºC, -30ºC~+70ºC/90ºC, 105/180ºC, 200ºC etc.
Payment	T/T, L/C, PayPal, Western Union

Cable Structure

NO.	Conductor (mm²)	Structure (N/mm)	Conductor DIA (mm)	Conductor	Thickness (mm)	Material	Insulation OD (mm)	20ºC Conductor Resistance (Ω/KM)
EV-YJ	1.5	48/0.20	1.60	copper	0.6	silicone	2.90±0.15	≤12.7
EV-YJ	2.5	80/0.20	2.06	copper	0.7	silicone	3.50±0.15	≤7.60
EV-YJ	4	128/0.20	2.62	copper	0.8	silicone	4.30±0.15	≤4.71
EV-YJ	6	196/0.20	3.50	copper	0.8	silicone	5.10±0.20	≤3.14
EV-YJ	10	322/0.20	4.50	copper	1.00	silicone	6.70±0.20	≤1.82
EV-YJ	16	513/0.20	5.70	copper	1.10	silicone	8.00±0.30	≤1.16
EV-YJ	25	798/0.20	7.10	copper	1.3	silicone	9.80±0.30	≤0.743
EV-YJ	35	1121/0.20	8.50	copper	1.3	silicone	11.40±0.30	≤0.527
EV-YJ	50	1596/0.20	10.10	copper	1.50	silicone	13.50±0.30	≤0.368
EV-YJ	70	2242/0.20	12.10	copper	1.50	silicone	15.50±0.40	≤0.259
EV-YJ	95	3034/0.20	14.10	copper	1.50	silicone	17.50±0.50	≤0.196

Frequently Asked Questions

1. Are you a manufacturer or trading company?

We are a professional manufacturer. We can control your order from the first beginning to the last. Welcome to visit us. We'll pick you up in Shenzhen.

2. How can I get a sample to test your quality?

The samples are free for you. New clients are expected to pay for the courier cost.

3. What's your Minimum Order Quantity?

Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.

4. Can I get a discount?

It depends on your quantity, We can make a discount and afford the freight. Please kindly contact us.

5. Does your company accept OEM production?

Yes, could print your company name, we even custom the quality card to promote your company.
