| Product Range: |
Automotive wireharness,Appliance wireharness,Robot wireharness,Medical wireharness and etc. |
| Test: |
Professional breakover and pulling force test before shipment |
| Cable materials: |
Wire harness can be UL/CSA,CE, etc and pure copper |
| Cable color,length: |
According to the customers' requirements |
| Insulation: |
Rubber,Silica,PE,...etc |
| Connector and Terminal Type |
Original OEM or Replacement |
| Application |
Automotive,Appliance equipment,Medical equipment and etc |
| MOQ |
1000PCS |
| Samples |
Samples confirmed first before mass production |
| Certificates |
ISO9001-2015, IATF16949-2016, CE, RoHS, SGS, TUV |
| Lead time |
10-20days |
| Service |
OEM and ODM, we accept customization according to your requirement |
| Nominal Voltage |
300V,300/500V,600V,30V,450/750V etc… |
| Temperature Range |
-30ºC~+80ºC,-30ºC~+90ºC,-30ºC~+105ºC,-30ºC~+70ºC/90ºC,105/180ºC, 200ºC etc…. |
| Lead time |
Small orders under 500pcs is 5-7days,exceed 1000pcs 7-15days |
| Payment |
T/T, L/C,PayPal,Western Union |
| Style: EV-YJ 1.5mm2~95mm2 |
|
|
|
|
|
|
| Structure |
| NO. |
conductor mm2 |
insulution |
20ºC conductor resistance (Ω/KM) |
| conductor mm2 |
Structure(N/mm) |
Conductor DIA(mm) |
Conductor |
Thickness (mm) |
MATERIAL |
insulution OD (mm) |
| EV-YJ |
1.5 |
48/0.20 |
1.60 |
copper |
0.6 |
silicone |
2.90±0.15 |
≤12.7 |
| EV-YJ |
2.5 |
80/0.20 |
2.06 |
copper |
0.7 |
silicone |
3.50±0.15 |
≤7.60 |
| EV-YJ |
4 |
128/0.20 |
2.62 |
copper |
0.8 |
silicone |
4.30±0.15 |
≤4.71 |
| EV-YJ |
6 |
196/0.20 |
3.50 |
copper |
0.8 |
silicone |
5.10±0.20 |
≤3.14 |
| EV-YJ |
10 |
322/0.20 |
4.50 |
copper |
1.00 |
silicone |
6.70±0.20 |
≤1.82 |
| EV-YJ |
16 |
513/0.20 |
5.70 |
copper |
1.10 |
silicone |
8.00±0.30 |
≤1.16 |
| EV-YJ |
25 |
798/0.20 |
7.10 |
copper |
1.3 |
silicone |
9.80±0.30 |
≤0.743 |
| EV-YJ |
35 |
1121/0.20 |
8.50 |
copper |
1.3 |
silicone |
11.40±0.30 |
≤0.527 |
| EV-YJ |
50 |
1596/0.20 |
10.10 |
copper |
1.50 |
silicone |
13.50±0.30 |
≤0.368 |
| EV-YJ |
70 |
2242/0.20 |
12.10 |
copper |
1.50 |
silicone |
15.50±0.40 |
≤0.259 |
| EV-YJ |
95 |
3034/0.20 |
14.10 |
copper |
1.50 |
silicone |
17.50±0.50 |
≤0.196 |
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
2,Low viscosity appearance
Conductor : Flexible Bare annealed copper wire
Insulation:Silicone
Choice of Black, Orange, Red or Yellow Blue jacket, single & double insulated.
SQ MM sizes (European style) :4 sq mm to 240 sq mm
AWG sizes (North American style) :0AWG-10AWG,
Wide temperature range: -60°C to 200°C
Our certification:
We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269(Single conductor,thermoplastic insulation)
UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,UL2587,
UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664
ISO9001 and ISO13485,TS16949
CNR- Appliance Wiring Material,
Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.
Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.
Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2
- Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last.
- Welcome to visit us. We'll pick you up in Shenzhen.
- How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.
- What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy.
You'd better order a suitable quantity to avoid the high freight.
Sea transportation is the best option.
- Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.
- Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company
