UL20233 TPU Insulated Cable - 300V Rated
Product Specifications
- Style Number: UL20233
- Rated Temperature: 80°C
- Rated Voltage: 300V
- Spark Voltage: 3KV
- Dielectric Strength: 2000Vac for 60 seconds without breakdown
- Flammability Grade: VW-1, FT1, FT2
Construction Details
- Conductor Material: High purity copper wire strands, tinned or bare, optional
- Conductor Size: 36AWG or more
- Insulation: AWM complying material
- Insulation Colour: Black, brown, red, orange, yellow, green, blue, violet, gray, white, pink, transparent, etc.
- Core Quantity: 2 cores or above
- All individually insulated conductor wires cabled together, twisted lay length to be determined
- Sheath: High quality Thermoplastic TPU material
- Sheath Effect: Glossy, Matt, Half matt
- Screen Shield: tinned copper wire strands, or spiral wrapped with aluminum foil
- Shield Coverage: 65% minimum
- Standard: AWM, UL758, UL1581
Performance Features
- Agile routing and handling
- High flexibility, suitable to be coiled as curly spiral cable
- Uniform insulation thickness for easy stripping
- Resistant to oil, organic solvent, strong acid, gas, and other chemicals
- Hydrolysis resistant, excellent performance to be mounted with waterproof connector
- UV resistant
- Capable of handling temperature extremes to -50°C
Applications
- Electronic equipment wiring purpose
- Case examples: Christmas Light, Diesel Generator, Gantry Crane, etc.
Environmental Compliance
- No contain of halogens, phthalates, or heavy metals
- RoHS, and RoHS2.0 compliant
- Reach compliant
- WEEE compliant
Technical Specifications Table
| Conductor Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal thickness (mm) |
Diameter (mm) |
Core |
Shield |
Shield Rate (%) |
Nominal thickness (mm) |
Diameter (mm) |
Max. Conductor Resistance (Ω/KM) Bare copper |
Max. Conductor Resistance (Ω/KM) Tinned copper |
| 26 |
7/0.16 |
0.48 |
0.23 |
1.00±0.10 |
2 |
Optional |
65 |
0.76 |
3.50±0.10 |
140 |
150 |
| 3 |
|
|
|
3.70±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
3.90±0.15 |
|
|
|
|
|
|
| 24 |
7/0.20 |
0.60 |
0.23 |
1.10±0.10 |
2 |
Optional |
65 |
0.76 |
3.70±0.15 |
87.6 |
94.2 |
| 3 |
|
|
|
3.90±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
4.20±0.15 |
|
|
|
|
|
|
| 22 |
7/0.254 |
0.78 |
0.23 |
1.30±0.10 |
2 |
Optional |
65 |
0.76 |
4.10±0.15 |
55.4 |
59.4 |
| 3 |
|
|
|
4.30±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
4.70±0.15 |
|
|
|
|
|
|
| 20 |
26/0.16 |
0.94 |
0.23 |
1.50±0.10 |
2 |
Optional |
65 |
0.76 |
4.50±0.15 |
34.6 |
36.7 |
| 3 |
|
|
|
4.80±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
5.10±0.15 |
|
|
|
|
|
|
| 18 |
41/0.16 |
1.18 |
0.23 |
1.80±0.10 |
2 |
Optional |
65 |
0.76 |
5.10±0.15 |
21.8 |
23.2 |
| 3 |
|
|
|
5.40±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
5.90±0.15 |
|
|
|
|
|
|
| 16 |
26/0.254 |
1.49 |
0.23 |
2.10±0.10 |
2 |
Optional |
65 |
0.76 |
5.70±0.15 |
13.7 |
14.6 |
| 3 |
|
|
|
6.00±0.15 |
|
|
|
|
|
|
| 4 |
|
|
|
6.60±0.15 |
|
|
|
|
|
|
Note: Wire specifications can be customized
Available Colors
Black, Brown, Red, Orange, Yellow, Green, Blue, Purple, Gray, White, Yellow/Green, Transparent
Manufacturer Profile
Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China. In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of wire and cable. Linke provide various cables & custom cable solutions for all over the world.
We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable, towlobe cable, UL wire, automotive cable, etc.
At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-engineer approach to develop better cables for customers and improve the quality of one's life.
