Refined Pure Oxygen Free Copper Gxl Cable For Mobile Appliances

Refined Pure Oxygen Free Copper Gxl Cable For Mobile Appliances

Oxygen Free Copper Gxl Cable

Mobile Gxl Cable

Copper Gxl Automotive Wire

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Model NO.:
Gxl Cable
Conductor Type:
Twisted Wire
Insulated Material:
PVC
Jacket:
TPE
Conductor:
Bare Copper
Conductor Material:
Copper/Tinned Copper
Exterior Material:
Customize:PVC、PE、LSFOH、silicone Rubber
Insulating Materials:
Customize:PVC、PE 、XLPE、EPR、SIR
Specifications:
0.1-450mm²
Rated Voltage:
300-600V
Colour:
Customize
Type:
Insulated
Highlight:

Oxygen Free Copper Gxl Cable

,

Mobile Gxl Cable

,

Copper Gxl Automotive Wire

Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
Product Description

Refined Pure Oxygen Free Copper Gxl Cable for Mobile Appliances



TYPE conductor DIA.(mm) VOLTAGE Materal Color
1007#22AWG 17/0.14TS 17/0.14TS 0.16 300V Tinned copper+PVC custom
1007#22AWG 17/0.13TS  17/0.13TS 0.16 301V Tinned copper+PVC custom
1007#22AWG 17/0.13TS  17/0.13TS 0.16 302V Tinned copper+PVC custom
1007#22AWG 17/0.12TS 17/0.12TS 0.16 303V Tinned copper+PVC custom
1007#22AWG 17/0.12TS  17/0.12TS 0.16 304V Tinned copper+PVC custom



Mobile Appliances Refined Pure Oxygen Free Copper Gxl Cable
►Application
Low-tension electric wire for Automobiles.
Used in Motorcycles and other motor vehicles for starting, charging, lighting, signal and instrument panel circuits.
Especially used for circuits requiring heat resistance.
►Product construction
Conductor : Soft-annealed electrolytic Copper E- Cu ETP1 according to ASTM B3 bare conductor construction according to SAE J 1128
Insulation : Electron Beam Cross Linked Polyolefin.
Colour : As per customer order.
Single core
►Technical data
Temperature Range: – 40°C to +125°C (3000 Hours)
Standard: SAE J1128
Test Voltage: 1kV
GXL: General Purpose XLPO insulation.
Conductor Resistance:IEC 60228/BS 6360
►Features
Flame retardant.
Highly resistant against acids, lyes, Petrol and diesel
Flexible conductors with PVC thin wall insulation for smaller diameter and lesser weight.
Extra flexibility.
Heat resistant.
2,Low viscosity appearance



Company Profile:

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China. In the past over 10 years,

Linke Cable has been focusing on R&D, production and marketing of wire and cable. Linke provide various cables&custom

cable solutions for all over the world. We are specialized in EV charging cable, medical cable, silicone cable, spring cable,

braided cable, towlobe cable, UL wire, automotive cable, etc.

At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-engineer approach

to develop better cables for customers and  improve the quality of one's life.
Mobile Appliances Refined Pure Oxygen Free Copper Gxl Cable

Mobile Appliances Refined Pure Oxygen Free Copper Gxl CableMobile Appliances Refined Pure Oxygen Free Copper Gxl CableMobile Appliances Refined Pure Oxygen Free Copper Gxl Cable
