Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug

Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug

Custom Flexible Flat Copper Busbar

Battery Copper Busbar

30.000kg Package Gross Weight Copper Busbar

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C，UL，TPU，UL758，ROHS，REACH，CE，ISO9001-2015，ISO13485，IATF16949

Contact Us
Request A Quote
Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug
Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug
Product Details
Model NO.:
Copper Busbar
AMP:
1200A
Color:
Customized
Plug Type:
IEC 62196-2 (Type 2), SAE J1772 Type 1
Certification:
UL;ISO9001;ISO13485;IATF16949;TPU
Samples:
US$ 1000/PCS 1 PCS(Min.Order) |
Customization:
Available
Return&refunds:
You Can Apply For A Refund Up To 30 Days After Receipt Of The Products.
Conductor Type:
Twisted Wire
Exterior Material:
Customize：PVC、PE、LSFOH、silicone Rubber
Insulating Materials:
Customize:PVC、PE 、XLPE、EPR、SIR
Specifications:
0.1-450mm²
Rated Voltage:
300-600V
Rated Temperature:
-60± 200℃
Type:
Insulated
Package:
By Roll
Core:
Multiple
Lead Time:
7-15days
Highlight:

Custom Flexible Flat Copper Busbar

,

Battery Copper Busbar

,

30.000kg Package Gross Weight Copper Busbar

Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
RELATED PRODUCTS
Good price UL 600V 16AMP 3*14AWG+1*18AWG AC EV Wire EV Charging Cable online Video

UL 600V 16AMP 3*14AWG+1*18AWG AC EV Wire EV Charging Cable

Get Best Price
Good price UL2464 Multi-Core Power Wire with 300V Rated Voltage 80ºC Temperature Rating and Tinned Copper Conductor for Industrial Control online Video

UL2464 Multi-Core Power Wire with 300V Rated Voltage 80ºC Temperature Rating and Tinned Copper Conductor for Industrial Control

Get Best Price
Good price UL Aprroved PVC XLPE Insulated Multi Conductor Flexible Power Wire Electric Cable online Video

UL Aprroved PVC XLPE Insulated Multi Conductor Flexible Power Wire Electric Cable

Get Best Price
Good price Automotive Industrial Wire Cable Harness OEM ODM Auto Molex Jst Connector Plug EV Charger Cable online

Automotive Industrial Wire Cable Harness OEM ODM Auto Molex Jst Connector Plug EV Charger Cable

Get Best Price
Contact Us
86-0769-81776230
86-18665106395
sales@linkecable.com
Contact Now
Product Description
Insulated Custom Flexible Flat Copper Busbar for Battery EV Charger Cable
Premium Flexible Copper Busbar for New Energy Vehicle Applications
Our insulated custom flexible flat copper busbar is engineered for battery and EV charger cable applications. The product features 99.9% pure copper content through brazed copper foil construction, delivering excellent conductivity with minimal impurities. The laminated design provides increased current-carrying surface area.
Product Specifications
Material Standard GB: T2 Copper with Min. 99.9%
DIN: E-Cu58 (Number: 2.0065)
EN: Cu-ETP (Number: CW004A)
ISO: Cu-ETP
UNS: C11000
JIS: C1100
BS: C101
Other materials available upon request
Key Parameters Resistance: 0.00001Ω
Conductivity: 57%
Copper Foil Thickness: 0.1/0.2/0.3/0.5/1.0mm (customizable)
Operating Temperature: -45°C to +150°C
Copper Foil Tensile Strength: ≥500N
Insulation Properties Material: PVC Dipping Coating (excellent performance)
Performance: Superior to PE heat shrink tubes
Flame Retardant: UL94-V-0 standard (customizable)
Leakage Testing: 3500VDC/30s (1.5mm) - 0.025 MA; 5000VAC/30-60s (1.8-2.0mm) - 0.065 MA
Surface Treatment Plating Options: Nickel, tin, or silver
Plating Thickness: 3μm to 12μm (standard)
Salt Spray Resistance: Nickel withstands 240 hours in neutral environment
Performance Testing
  • Bending Test: 10,000 cycles at 15° angle without breakage
  • Temperature Rise Testing: Custom reports available based on cross-sectional area
  • Quality Standards: IATF 16949 automotive industry compliant
  • Certifications: ROHS, REACH eco-friendly compliant
Product Variations
Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug 0
PVC Insulated Option
  • Conductor: Flexible bare annealed copper wire
  • Insulation: Copper with PVC coating
  • Color Options: Black, Orange, Red, Yellow, Blue
  • Size Customization: European (SQ MM) or North American (AWG) standards
Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug 1
Silicone Insulated Option
  • Conductor: Flexible bare annealed copper wire
  • Insulation: High-grade silicone
  • Temperature Range: -60°C to 200°C
  • Size Range: 4 sq mm to 240 sq mm (European) or 0AWG-10AWG (North American)
About Linke Cable Technology Co., Ltd

As a leading Chinese cable manufacturer with over 10 years of experience, we specialize in R&D, production, and marketing of high-quality cables. Our expertise includes EV charging cables, medical cables, silicone cables, and automotive cables. We maintain certifications including ISO9001, ISO13485, and TS16949.

Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug 2 Customized 1200A AMP Flexible Copper Busbar with IEC 62196-2 and SAE J1772 Type 1 Plug 3
Frequently Asked Questions
1. Are you a manufacturer or trading company?

We are a professional manufacturer with complete control over production. Visitors are welcome - we provide pickup service in Shenzhen.

2. How can I get a sample to test your quality?

Samples are free for evaluation, with new clients responsible for courier costs.

3. What's your Minimum Order Quantity?

Standard MOQ is 100m. For heavy cables, we recommend larger quantities for cost-effective shipping, preferably via sea freight.

4. Can I get a discount?

Discounts are available based on order quantity. Contact us for customized pricing.

5. Does your company accept OEM production?

Yes, we offer complete OEM services including company branding and customized quality cards.
